| Image Sensor1/2.8" Progressive Scan CMOS |
Max resolution3K(3072*1728) |
Main Stream50 Hz: 25fps (3072*1728, 2560*1440, 1920*1080, 1280*960, 1280*720)
60 Hz: 30fps(3072*1728, 2560*1440, 1920*1080, 1280*960, 1280*720) |
Sub-stream50 Hz: 25 fps (704*480,640*480, 352*240)
60 Hz: 30 fps (704*480,640*480, 352*240) |
Third stream50 Hz: 10 fps (704*480,640*480, 352*240)
60 Hz: 10 fps (704*480,640*480, 352*240) |
Video CompressionMain stream: H.265+/H.265/H.264+/H.264
Sub-stream: H.265/H.264/MJPEG
Third stream: H.265/H.264/MJPEG |
| Video Bit Rate256 Kbps - 16384 kbps |
Audio InputBuilt-in microphone, record with audio |
| Audio OutputBuilt-in Speaker, support 2- way audio and audio alarm |
Audio CompressionG.711ulaw/G.711alaw/G.722.1/G.726/MP2L2/PCM/AAC |
| Audio Bit rate64 Kbps (G.711),16 Kbps (G.722.1),32 to 160 Kbps (MP2L2),16 to 64Kbps (AAC-LC),16 Kbps (G.726) |
Audio Sampling Rate8 kHz |
| Lens2.8-12 mm, 4x optical zoom, 16x digital Zoom |
Shutter Speed1/1 s to 1/30,000 s |
| Slow ShutterYes |
Min. IlluminationColor: 0.005 lux @ (ƒ/1.8, AGC on), b/w: 0.001 lux @ (ƒ/1.8, AGC on), 0 lux with IR |
| Angle of ViewHorizontal FOV 99.4° to 32.8°, vertical FOV 51.7° to 18.4°, diagonal FOV 119.9° to 37.5° |
PT Movement RangePAN: 0° to 355°,Tilt: From 0° to 90° |
| PT SpeedConfigurable, from 0.1°/s to 50°/s, preset speed: 50°/s |
Presets300 |
| Park ActionPreset,patrol scan |
Scheduled TaskPatrol scan, Preset, dome reboot, dome adjust |
| Number of Infrared LEDs4 pcs |
Night Vision DistanceUp to 65 ft/20 m |
| Image Enhancement3D DNR, HLC, regional exposure, regional focus, digital defog |
Wide Dynamic Range120 dB True WDR |
| ProtocolsIPv4/IPv6, HTTP, HTTPS, 802.1x, Qos, FTP, SMTP, UPnP, SNMP, DNS, DDNS, NTP, RTSP, RTCP, RTP, TCP/IP, UDP, IGMP, ICMP, DHCP, PPPoE, Bonjour |
APIOpen Network Video Interface (Version 19.12, Profile S, Profile G, Profile T), ISUP |
| Region of Interest (ROI)1 fixed regions for each stream |
Privacy Mask8 programmable polygon privacy masks, mask color or mosaic configurable |
| Basic EventMotion detection, video tampering alarm, exception, audio exception detection |
Smart EventLine crossing detection, intrusion detection, region entrance detection, region exiting detection |
| General FunctionMirror, acuseek |
Ethernet1 RJ45 10M/100M self-adaptive Ethernet port |
Audio1 input (line in), max. input amplitude: 2-2.4 vpp, input impedance: 1 KΩ ± 10%;
1 output (line out), line level, output impedance: 600 Ω |
Power Output12 VDC, max. 60 mA |
| MaterialAluminum alloy, PC, PC + ABS |
|
| Image Sensor1/2.8" Progressive Scan CMOS |
| Max resolution3K(3072*1728) |
Main Stream50 Hz: 25fps (3072*1728, 2560*1440, 1920*1080, 1280*960, 1280*720)
60 Hz: 30fps(3072*1728, 2560*1440, 1920*1080, 1280*960, 1280*720) |
Sub-stream50 Hz: 25 fps (704*480,640*480, 352*240)
60 Hz: 30 fps (704*480,640*480, 352*240) |
Third stream50 Hz: 10 fps (704*480,640*480, 352*240)
60 Hz: 10 fps (704*480,640*480, 352*240) |
Video CompressionMain stream: H.265+/H.265/H.264+/H.264
Sub-stream: H.265/H.264/MJPEG
Third stream: H.265/H.264/MJPEG |
| Video Bit Rate256 Kbps - 16384 kbps |
| Audio InputBuilt-in microphone, record with audio |
| Audio OutputBuilt-in Speaker, support 2- way audio and audio alarm |
| Audio CompressionG.711ulaw/G.711alaw/G.722.1/G.726/MP2L2/PCM/AAC |
| Audio Bit rate64 Kbps (G.711),16 Kbps (G.722.1),32 to 160 Kbps (MP2L2),16 to 64Kbps (AAC-LC),16 Kbps (G.726) |
| Audio Sampling Rate8 kHz |
| Lens2.8-12 mm, 4x optical zoom, 16x digital Zoom |
| Shutter Speed1/1 s to 1/30,000 s |
| Slow ShutterYes |
| Min. IlluminationColor: 0.005 lux @ (ƒ/1.8, AGC on), b/w: 0.001 lux @ (ƒ/1.8, AGC on), 0 lux with IR |
| Angle of ViewHorizontal FOV 99.4° to 32.8°, vertical FOV 51.7° to 18.4°, diagonal FOV 119.9° to 37.5° |
| PT Movement RangePAN: 0° to 355°,Tilt: From 0° to 90° |
| PT SpeedConfigurable, from 0.1°/s to 50°/s, preset speed: 50°/s |
| Presets300 |
| Park ActionPreset,patrol scan |
| Scheduled TaskPatrol scan, Preset, dome reboot, dome adjust |
| Number of Infrared LEDs4 pcs |
| Night Vision DistanceUp to 65 ft/20 m |
| Image Enhancement3D DNR, HLC, regional exposure, regional focus, digital defog |
| Wide Dynamic Range120 dB True WDR |
| ProtocolsIPv4/IPv6, HTTP, HTTPS, 802.1x, Qos, FTP, SMTP, UPnP, SNMP, DNS, DDNS, NTP, RTSP, RTCP, RTP, TCP/IP, UDP, IGMP, ICMP, DHCP, PPPoE, Bonjour |
| APIOpen Network Video Interface (Version 19.12, Profile S, Profile G, Profile T), ISUP |
| Region of Interest (ROI)1 fixed regions for each stream |
| Privacy Mask8 programmable polygon privacy masks, mask color or mosaic configurable |
| Basic EventMotion detection, video tampering alarm, exception, audio exception detection |
| Smart EventLine crossing detection, intrusion detection, region entrance detection, region exiting detection |
| General FunctionMirror, acuseek |
| Ethernet1 RJ45 10M/100M self-adaptive Ethernet port |
Audio1 input (line in), max. input amplitude: 2-2.4 vpp, input impedance: 1 KΩ ± 10%;
1 output (line out), line level, output impedance: 600 Ω |
| Power Output12 VDC, max. 60 mA |
| MaterialAluminum alloy, PC, PC + ABS |
