ANNKE HWZ500 - 5MP 8CH 4 Cameras PoE Security System + 20X PTZ WiFi Camera

HWZ500 - 5MP 8 Channel Four Cameras PoE Security System + One 20X PTZ WiFi Camera, Infrared Night Vision, Built-in Microphone, Works with Alexa

HWZ500 - 5MP 8 Channel Four Cameras PoE Security System + One 20X PTZ WiFi Camera, Infrared Night Vision, Built-in Microphone, Works with Alexa

$299.99

$449.99

SKU: N48PBB+I51DL0102*4+I51CK

Appearance
Lens
HDD Capacity
Note:

Secure Checkout With:

  • Tags: 5 , 5MP , 8CH NVR , Built-in Microphone , Bullet , Color Night Vision , Dome , Dual Lights Night Vision , EXIR Night Vision , Optical Zoom , Pan Tilt , Turret , Two-Way Audio

    H500 System + WZ500

    Up Your Smart Solution
    Game to True 5MP PoE


  • 8CH

    NVR
    Support Max. 8 Cams

  • 2.8/4 MM

    Up to 91° FOV
    Cover Every Angle

  • IP67

    Outdoor
    Indoor Use

  • 100 FT

    EXIR Night Vision
    View Clearly at Night

  • Heightened 5MP Super HD in All Environments

    H500 has been tested in almost every scenario in your daily life, garages, front doors, stores, etc. both hot & cold temperatures. The cameras can still shoot stable & high-fidelity footages without glare in every testing environment.

    Color Night Vision with External Lighting

    ANNKE-designed color night vision tech enables the camera to produce colorful videos over 0.028 lux illumination with the external light sources around the camera.

    Equipped with the exceptional EXIR tech & smart IR, the camera delivers up to 100 ft long-range black & white night vision in 0 lux illumination conditions, which are too dark to render color images.

    Noise-Cancelling Audio Recording

    The built-in noise-cancelling microphone can filter the environment noise automatically, and pick up the voice from up to 20 ft away.

    Listen-in Audio

    Audio recording enhances the security coverage and the ability to interpret events. Record videos with vivid sound instead of silent footages.

    Mute Function

    Audio record might be regulated based on your location. If the audio surveillance is not allowed or you don’t want audio record, simply mute it.

    Advanced H.265+ Video Format

    ANNKE H.265+ coding helps the camera record longer videos and consumes less bandwidth. Save your budgets on buying more HDDs.

  • Small File Sizes

    Send smaller file sizes to the network video recorder without losing 5MP quality.

  • Long Recording Time

    H.265+ coding allows for longer recording time before overwriting the older recordings.

  • Remote 5MP Live View

    View high-quality 5MP Super HD live stream on your smart devices without all the data.

  • Heavy-Duty IK10 Vandal-Proof Housing

    The rugged dome security camera is manufactured with an IK10 vandal-proof rating. It means that your camera can withstand devastating violent impacts (for dome cameras only).

    Made from metal & ABS materials (provided by SABIC, the largest public company in the Middle East & Saudi Arabia), it is capable of looking after itself while protecting you.

    Built to Brave Extreme Hot & Cold Climates

    Rated as IP67, this weatherproof camera can withstand pretty much anything, regardless heavy snowfall, torrential downpours. This camera has been tested in extreme temperatures (-22 °F to 140 °F), ensuring all-year-round protection wherever you live.

  • Metal & ABS

    Rugged Housing

  • 140 °F | 60 °C

    Heat Rating

  • -22 °F | -30 °C

    Cold Rating

  • IP67

    Water Rating

  • Triple & Flexible Video Recording Modes

    Your NVR can record videos continuously, during scheduled periods or when motion is detected. The recording modes can be specified for each camera, so you can customize the cameras in higher activity areas to record 24/7, while cameras in low activity areas can be set up to record motion events only.

    The built-in security-grade 2 TB HDD is engineered to meet the demands of 24/7 recording, without cloud storage fees. You may increase the storage space up to 6 TB.

    Simple Plug & Play PoE Installation

    Power over Ethernet (PoE) tech is the all-in-one solution that reduces the cost and installation time. A single Ethernet cable runs between your IP camera and network video recorder provides power, video & network transmission, so you don’t need to install your camera near an outlet.

    Smart Motion Detection Alerts

    Whenever there are motion events, you will receive real-time app push notifications and email alerts with snapshots, which allows you to keep track of all motion activities easily & instantly.

    Small on Prices, Big on Features

  • Support RTSP

    Integrate the system to third-party software 4K cameras, like Blue Iris, Synology, etc.

  • Customized Motion Areas

    Customize the specific motion zones, like garage, front door, etc. for much more relevant motion alerts.

  • Unlimited Remote Access

    Easily access your system via intuitive ANNKE Vision App from virtually anywhere in the world.

  • 24/7 Record Without Internet

    The NVR & cameras link to each other after plug in & record videos 24/7 without Internet.

  • Note: Please refer to the description for WZ500.

    Specification

    Download H500 Specification

    What's in the Box
  • ➀ 1X NVR
  • ➁ 5MP PoE Cameras (The quantity varies based on your choice.)
  • ➂ 60 ft/18 m Ethernet Cables
  • ➃ 100 ft/30 m Ethernet Cables (The quantity varies based on your choice.)
  • ➄ 1X Network Cable
  • ➅ 1X HDMI Cable
  • ➆ Mounting Screw Bags
  • ➇ 1X USB Mouse
  • ➈ 1X Power Adapter
  • ➉ User Manual
  • Camera
    Image Sensor1/3" Progressive Scan CMOS Video Resolution5MP (2560 X 1920 @15 fps)
    Signal SystemPAL/NTSC Video CompressionH.265+/H.265/H.264+/H.264
    Video Bitrate32 Kbps — 8 Mbps Lens2.8 mm
    Min. IlluminationColor: 0.01 Lux @(F2.0, AGC On) Angle of ViewHorizontal FoV 71.5°, Vertical FoV 53°, Diagonal FoV 91°
    Number of Infrared LEDs2 pcs Night Vision DistanceUp to 100 ft/30 m
    DNR3D DNR Wide Dynamic RangeDigital WDR
    EthernetRJ45 X1 (10 M/100 M) IR-Cut FilterYes
    Image Sensor1/3" Progressive Scan CMOS
    Signal SystemPAL/NTSC
    Video Bitrate32 Kbps — 8 Mbps
    Min. IlluminationColor: 0.01 Lux @(F2.0, AGC On)
    Number of Infrared LEDs2 pcs
    DNR3D DNR
    EthernetRJ45 X1 (10 M/100 M)
    Video Resolution 5MP (2560 X 1920 @15 fps)
    Video Compression H.265+/H.265/H.264+/H.264
    Lens 2.8 mm
    Angle of View Horizontal FoV 71.5°, Vertical FoV 53°, Diagonal FoV 91°
    Night Vision Distance Up to 100 ft/30 m
    Wide Dynamic Range Digital WDR
    IR-Cut Filter Yes
    General
    HousingMetal & Plastic ColorWhite
    Operating PowerDC 12 V; PoE (802.3af) Operating Temperature-22 °F — 140 °F/-30 °C — 60 °C
    Indoor/OutdoorIndoor/Outdoor Weatherproof RatingIP67
    Dimension (L X W X H)6.8" X 2.6" X 2.72"/172.7 X 66 X 69.1 mm Weight0.7 lb./300 g
    HousingMetal & Plastic
    Operating PowerDC 12 V; PoE (802.3af)
    Indoor/OutdoorIndoor/Outdoor
    Dimension (L X W X H)6.8" X 2.6" X 2.72"/172.7 X 66 X 69.1 mm
    Color White
    Operating Temperature -22 °F — 140 °F/-30 °C — 60 °C
    Weatherproof Rating IP67
    Weight 0.7 lb./300 g
    What's in the Box
  • ➀ 1X NVR
  • ➁ 5MP PoE Cameras (The quantity varies based on your choice.)
  • ➂ 60 ft/18 m Ethernet Cables
  • ➃ 100 ft/30 m Ethernet Cables (The quantity varies based on your choice.)
  • ➄ 1X Network Cable
  • ➅ 1X HDMI Cable
  • ➆ Mounting Screw Bags
  • ➇ 1X USB Mouse
  • ➈ 1X Power Adapter
  • ➉ User Manual
  • Camera
    Image Sensor1/3" Progressive Scan CMOS Video Resolution5MP (2560 X 1920 @15 fps)
    Signal SystemPAL/NTSC Video CompressionH.265+/H.265/H.264+/H.264
    Video Bitrate32 Kbps — 8 Mbps Lens2.8 mm
    Min. IlluminationColor: 0.01 Lux @(F1.2, AGC On) Angle of ViewHorizontal FoV 71.5°, Vertical FoV 53°, Diagonal FoV 91°
    Number of Infrared LEDs2 pcs Night Vision DistanceUp to 100 ft/30 m
    DNR3D DNR Wide Dynamic RangeDigital WDR
    EthernetRJ45 X1 (10 M/100 M) IR-Cut FilterYes
    Image Sensor1/3" Progressive Scan CMOS
    Signal SystemPAL/NTSC
    Video Bitrate32 Kbps — 8 Mbps
    Min. IlluminationColor: 0.01 Lux @(F1.2, AGC On)
    Number of Infrared LEDs2 pcs
    DNR3D DNR
    EthernetRJ45 X1 (10 M/100 M)
    Video Resolution 5MP (2560 X 1920 @15 fps)
    Video Compression H.265+/H.265/H.264+/H.264
    Lens 2.8 mm
    Angle of View Horizontal FoV 71.5°, Vertical FoV 53°, Diagonal FoV 91°
    Night Vision Distance Up to 100 ft/30 m
    Wide Dynamic Range Digital WDR
    IR-Cut Filter Yes
    General
    HousingMetal & Plastic ColorWhite
    Operating PowerDC 12 V; PoE (802.3af) Operating Temperature-22 °F — 140 °F/-30 °C — 60 °C
    Indoor/OutdoorIndoor/Outdoor Weatherproof RatingIP67
    Dimension (L X W X H)4.3" X 3.7"/110 X 93.2 mm Weight0.9 lb./400 g
    HousingMetal & Plastic
    Operating PowerDC 12 V; PoE (802.3af)
    Indoor/OutdoorIndoor/Outdoor
    Dimension (L X W X H)4.3" X 3.7"/110 X 93.2 mm
    Color White
    Operating Temperature -22 °F — 140 °F/-30 °C — 60 °C
    Weatherproof Rating IP67
    Weight 0.9 lb./400 g
    What's in the Box
  • ➀ 1X NVR
  • ➁ 5MP PoE Cameras (The quantity varies based on your choice.)
  • ➂ 60 ft/18 m Ethernet Cables
  • ➃ 100 ft/30 m Ethernet Cables (The quantity varies based on your choice.)
  • ➄ 1X Network Cable
  • ➅ 1X HDMI Cable
  • ➆ Mounting Screw Bags
  • ➇ 1X USB Mouse
  • ➈ 1X Power Adapter
  • ➉ User Manual
  • Camera
    Image Sensor1/2.7" Progressive Scan CMOS Video Resolution5MP (2560 X 1920 @15 fps)
    Signal SystemPAL/NTSC Video CompressionH.265/H.264
    Video Bitrate32 Kbps — 8 Mbps Lens4 mm
    Min. IlluminationColor: 0.01 Lux @(F1.2, AGC On) Angle of View75°
    Number of Infrared LEDs30 pcs Night Vision DistanceUp to 100 ft/30 m
    DNR3D DNR Wide Dynamic RangeDigital WDR
    EthernetRJ45 X1 (10 M/100 M) IR-Cut FilterYes
    Image Sensor1/2.7" Progressive Scan CMOS
    Signal SystemPAL/NTSC
    Video Bitrate32 Kbps — 8 Mbps
    Min. IlluminationColor: 0.01 Lux @(F1.2, AGC On)
    Number of Infrared LEDs30 pcs
    DNR3D DNR
    EthernetRJ45 X1 (10 M/100 M)
    Video Resolution 5MP (2560 X 1920 @15 fps)
    Video Compression H.265/H.264
    Lens 4 mm
    Angle of View 75°
    Night Vision Distance Up to 100 ft/30 m
    Wide Dynamic Range Digital WDR
    IR-Cut Filter Yes
    General
    HousingMetal & Plastic ColorWhite
    Operating PowerDC12V;PoE (802.3af) Operating Temperature-22 °F – 140 °F /-30 °C – 60 °C
    Indoor/OutdoorIndoor/Outdoor Weatherproof RatingIP67
    Vandal-Proof RatingIK10 Dimension (L X W X H)4.4" X 3.2"/111 X 82.4 mm
    Weight0.9 lb./400 g
    HousingMetal & Plastic
    Operating PowerDC12V;PoE (802.3af)
    Indoor/OutdoorIndoor/Outdoor
    Vandal-Proof RatingIK10
    Weight0.9 lb./400 g
    Color White
    Operating Temperature -22 °F – 140 °F /-30 °C – 60 °C
    Weatherproof Rating IP67
    Dimension (L X W X H) 4.4" X 3.2"/111 X 82.4 mm
    Video & Audio
    Video CompressionH.265+/H.265/ H.264+/H.264 IP Video Input8CH PoE
    Video OutputHDMI & VGA up to 1080p Incoming Bandwidth60 M
    Max Recording ResolutionUp to 6MP Max Playback ResolutionUp to 6MP
    Max Playback Channel8CH Max Playback Capacity4CH @1080p; 1CH @6MP
    Video CompressionH.265+/H.265/ H.264+/H.264
    Video OutputHDMI & VGA up to 1080p
    Max Recording ResolutionUp to 6MP
    Max Playback Channel8CH
    IP Video Input 8CH PoE
    Incoming Bandwidth 60 M
    Max Playback Resolution Up to 6MP
    Max Playback Capacity 4CH @1080p; 1CH @6MP
    Hard Drive
    HDD1 SATA Interface HDD CapacityUp to 6 TB Capacity
    HDD1 SATA Interface
    HDD Capacity Up to 6 TB Capacity
    External Interface
    Network InterfaceRJ45 X1 (10/100 M) PoE8 Ports (IEEE802.3at / af)
    USB2X USB 2.0
    Network InterfaceRJ45 X1 (10/100 M)
    USB2X USB 2.0
    PoE 8 Ports (IEEE802.3at / af)
    General
    Operating PowerDC 48 V Working Temperature14 °F — 131 °F/-10 °C — +55 °C
    Dimensions (W X H X D)10.4" X 8.9" X 1.9"/265 X 225 X 48 mm Weight (Without Hard Disk)2.2 lbs./1 kg
    Power Consumption≤10 W (Without HDD and PoE)
    PoE: Max 25.5 W for Single Port
    Operating PowerDC 48 V
    Dimensions (W X H X D)10.4" X 8.9" X 1.9"/265 X 225 X 48 mm
    Working Temperature 14 °F — 131 °F/-10 °C — +55 °C
    Weight (Without Hard Disk) 2.2 lbs./1 kg
    Power Consumption≤10 W (Without HDD and PoE)
    PoE: Max 25.5 W for Single Port
